JMTQ55P02A概述：
JMTQ55P02A是P沟道增强型功率MOSFET，
JMTQ55P02A是-20V,-55A的P沟MOSFET/RDS(ON) <8.5mΩ @ VGS = -4.5V RDS(ON) <12mΩ @ VGS = -2.5V
JMTQ55P02A丝印Q55P02A/JMTQ55P02A提供DFN3.3X3.3-8L封装

VDS=-20V, ID=-55A

RDS(ON) <8.5mΩ @ VGS = -4.5V

RDS(ON) <12mΩ @ VGS = -2.5V

High Power and Current Handing Capability

Lead Free Product is Acquired

Surface Mount Package

JMTQ55P02A丝印Q55P02A

JMTQ55P02A提供DFN3.3X3.3-8L封装

PWM Applications

Load Switch

订购信息：

Device Marking	Device	OUTLINE	evice Package	Reel Size	Reel (PCS)	Per Carton (PCS)
JMTQ55P02A	JMTQ55P02A	TAPING	PDFN3.3X3.3-8L	13inch	5000	50000

JMTQ55P02A典型应用电路图：
