JMTK50P02A概述：
JMTK50P02A是VDS=-20V,ID=-60A,RDS(ON)<8.5mΩ@VGS=-4.5V,RDS(ON)<12mΩ@VGS=-2.5V的P沟道增强型功率MOSFET。
JMTK50P02A的丝印是K50P02A。
JMTK50P02A提供TO-252封装。
JMTK50P02A是VDS=-20V,ID=-60A,RDS(ON)<8.5mΩ@VGS=-4.5V,RDS(ON)<12mΩ@VGS=-2.5V的P沟道增强型功率MOSFET。
JMTK50P02A的丝印是K50P02A。
JMTK50P02A提供TO-252封装。
JMTK50P02A特性:
VDS=-20V,ID=-60A
RDS(ON)<8.5mΩ@VGS=-4.5V
RDS(ON)<12mΩ@VGS=-2.5V
RDS(ON)<8.5mΩ@VGS=-4.5V
RDS(ON)<12mΩ@VGS=-2.5V
High Power and Current Handing Capability
Lead Free Product is Acquired
Surface Mount Package
JMTK50P02A应用：
PWM Applications
Load Switch
订购信息：
|
Device Marking
|
Device
|
OUTLINE
|
evice Package
|
Reel Size
|
Reel
(PCS)
|
Per Carton
(PCS)
|
|
JMTK50P02A
|
JMTK50P02A
|
TAPING
|
TO-252
|
13inch
|
2500
|
25000
|
JMTK50P02A典型应用电路图、丝印图、封装图：
