PE40P36K概述：
PE40P36K是VDS=-40V,ID=-36A，RDS(ON)<21mΩ，@VGS=-10V，RDS(ON)<32mΩ，@VGS=-4.5V的P-Channel Enhancement Mode Power MOSFET.PE40P36K的丝印是PE40P36K.PE40P36K提供TO-252-2L封装.
The PE40P36K uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
PE40P36K特性：
VDS = -40V, ID = -36A
RDS(ON) < 21mΩ @ VGS=-10V
RDS(ON) < 32mΩ @ VGS=-4.5V
High Power and current handing capability
Lead free product is acquired
Surface Mount Package
PE40P36K应用：
DC-DC converter
Load switch
Power management
PE40P36K典型应用及引脚图：
