PE7209M概述：
PE7209M是VDS=-20V,ID=-25A，RDS(ON)<16mΩ，@VGS=-4.5V，RDS(ON)<22mΩ，@VGS=-2.5V的P-Channel Enhancement Mode Power MOSFET.
PE7209M的丝印是PE7209M.PE7209M提供PDFN3.3x3.3-8L封装.
PE7209M的丝印是PE7209M.PE7209M提供PDFN3.3x3.3-8L封装.
The PE7209M uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
PE7209M特性：
PE7209M特性：
VDS = -20V, ID = -25A
RDS(ON) < 16mΩ @ VGS=-4.5V
RDS(ON) < 22mΩ @VGS=-2.5V
High Power and current handing capability
Lead free product is acquired
Surface Mount Package
PE7209M应用：
PE7209M应用：
PWM applications
Load switch
Power management
Battery protection
PE7209M典型应用及引脚：
PE7209M典型应用及引脚：
