PE3401是VDS=-30V,ID=-4.2A，RDS(ON)<50mΩ，@VGS=-10V，RDS(ON)<65mΩ,@VGS=-4.5VRDS(ON)<90mΩ,@VGS=-2.5V的P-Channel MOSFET.
PE3401提供SOT-23-3L封装.

The PE3401 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE3401概述：

PE3401是VDS=-30V,ID=-4.2A，RDS(ON)<50mΩ，@VGS=-10V，RDS(ON)<65mΩ,@VGS=-4.5VRDS(ON)<90mΩ,@VGS=-2.5V的P-Channel MOSFET.
PE3401提供SOT-23-3L封装.

The PE3401 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE3401特性：

VDS = -30V, ID = -4.2A

RDS(ON) < 50mΩ @ VGS=-10V

RDS(ON) < 65mΩ @VGS=-4.5V

RDS(ON) < 90mΩ @VGS=-2.5V

High Power and current handing capability

Lead free product is acquired

Surface Mount Package

PE3401应用：

PWM applications

Load switch

Power management

PE3401典型应用及引脚：
