PE8345G是VDS=30V，ID=45A，RDS(ON)<7.2mΩ@VGS=10V，RDS(ON)<13mΩ@VGS=4.5V的N沟道MOSFET。
PE8345G的丝印是PE8345G，PE8345G提供DFN5x6-8L封装。

The PE8345G uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE8345G概述：

PE8345G是VDS=30V，ID=45A，RDS(ON)<7.2mΩ@VGS=10V，RDS(ON)<13mΩ@VGS=4.5V的N沟道MOSFET。
PE8345G的丝印是PE8345G，PE8345G提供DFN5x6-8L封装。

The PE8345G uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE8345G特性：

VDS = 30V, ID = 45A

RDS(ON) < 7.2mΩ @ VGS=10V

RDS(ON) < 13mΩ @VGS=4.5V

High Power and current handing capability

Lead free product is acquired

Surface Mount Package

PE8345G应用：

Battery management

Motor controller and driver

PWM applications

Load switch

PE8345G典型应用及引脚：
