PE8810A概述：
PE8810A是VDS=18V，ID=8A，RDS(ON)<16mΩ @VGS=4.5V，RDS(ON)<18mΩ @VGS=3.8V，RDS(ON)<20mΩ @VGS=3.1V，RDS(ON)<22mΩ @VGS=2.5V的N沟道MOSFET.
PE8810A的丝印是PE8810A，PE8810A提供TSSOP-8封装。
PE8810A的丝印是PE8810A，PE8810A提供TSSOP-8封装。
The PE8810A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications. It is ESD protected.
PE8810A特性：
VDS = 18V, ID = 8A
RDS(ON) < 16mΩ @ VGS=4.5V
RDS(ON) < 18mΩ @VGS=3.8V
RDS(ON) < 20mΩ @VGS=3.1V
RDS(ON) < 22mΩ @VGS=2.5V
ESD Rating: 4000V HBM
High Power and current handing capability
Lead free product is acquired
Surface Mount Package
PE8810A应用：
PWM applications
Load switch
PE8810A典型应用及引脚：
