JMTK4005A是N沟道增强型功率MOSFET
JMTK4005A丝印K4005A
JMTK4005A提供TO-252-4R封装

40V,80A

RDS(ON)<5.5mΩ@VGS=10V

RDS(ON)<10mΩ@VGS=4.5V

Lead free and Green Device Available

Excellent RDS(ON) and Low Gate Charge

JMTK4005A概述:

JMTK4005A是N沟道增强型功率MOSFET，
JMTK4005A是40V,80A的N沟MOSFET/RDS(ON)<5.5mΩ@VGS=10V，RDS(ON)<10mΩ@VGS=4.5V，
JMTK4005A丝印K4005A，JMTK4005A提供TO-252-4R封装

JMTK4005A特性:

40V,80A

RDS(ON)<5.5mΩ@VGS=10V

RDS(ON)<10mΩ@VGS=4.5V

Lead free and Green Device Available

Excellent RDS(ON) and Low Gate Charge

Lead free product is acquired

JMTK4005A应用:

Load Switch

PWM Application

Power management

订购信息：

Device Marking	Device	OUTLINE	evice Package	Reel Size	Reel (PCS)	Per Carton (PCS)
JMTK4005A	JMTK4005A	TAPING	TO-252-4R	13inch	2500	25000

JMTK4005A典型应用电路图:
