MX8806B概述：
    MX8806B是VDS=15V,ID=6A，RDS(ON)<15mΩ,@VGS=4.5V,RDS(ON)<17mΩ,@VGS=3.8V,RDS(ON)<22mΩ,@VGS=2.5V的N沟道MOSFET.MX8806B提供SOT23-6封装。
    The MX8806B uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as 2.5V. This device is suitable for use as a load switch or in PWM applications.

MX8806B特性：
VDS = 15V,ID =6A
RDS(ON) < 15mΩ @ VGS=4.5V
RDS(ON) < 17mΩ @ VGS=3.8V
RDS(ON) < 22mΩ@ VGS=2.5V
High Power and current handing capability
Lead free product is acquired
Surface Mount Package

MX8806B应用:
PWM application
Load switch

MX8806B典型应用及引脚：
