PE2302概述：
    PE230是VDS=20V,ID=5A，RDS(ON)<45mΩ，@VGS=4.5V，RDS(ON)<55mΩ，@VGS=2.5V的N-Channel MOSFET.
    PE2302提供SOT-23-3L封装.
    The PE2302 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE2302特性：
VDS = 20V, ID =5A
RDS(ON) < 45mΩ@VGS=4.5V
RDS(ON) < 55mΩ @VGS=2.5V
High Power and current handing capability
Lead free product is acquired
Surface Mount Package

PE2302应用：
PWM applications
Load switch

PE2302典型应用及引脚：
