PE8126HM1概述：
PE8126HM1是VDS>12V,ID=26A，RDS(ON)<3.2mΩ，@VGS=4.5V，RDS(ON)<3.5mΩ，@VGS=3.8V，RDS(ON)<4.0mΩ，@VGS=3.1V，RDS(ON)<5.2mΩ，@VGS=2.5V的N-Channel Enhancement Mode Power MOSFET.PE8126HM1的丝印是8126HM。PE8126HM1提供DFN3x3-8L封装.
The PE8126HM1 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications. It is ESD protected.
PE8126HM1特性：
VDS > 12V, ID = 26A
RDS(ON) < 3.2mΩ @ VGS=4.5V
RDS(ON) < 3.5mΩ @VGS=3.8V
RDS(ON) < 4.0mΩ@VGS=3.1V
RDS(ON) < 5.2mΩ @VGS=2.5V
ESD Rating: 4000V HBM
High Power and current handing capability
Lead free product is acquired
Surface Mount Package
PE8126HM1应用：
PWM applications
Load switch
Power management
PE8126HM1典型应用及引脚：
