PE8203A概述：
PE8203A是VDS=18V,ID=7A，RDS(ON)<24mΩ，@VGS=4.5V，RDS(ON)<25mΩ，@VGS=3.8V，RDS(ON)<32mΩ，@VGS=2.5V的N-Channel Enhancement Mode Power MOSFET.PE8203A的丝印是PE8203A.PE8203A提供TSSOP-8封装.
The PE8203A uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.
PE8203A特性：
VDS = 18V, ID = 7A
RDS(ON) < 24mΩ @ VGS=4.5V
RDS(ON) < 25mΩ@VGS=3.8V
RDS(ON) < 32mΩ @VGS=2.5V
High Power and current handing capability
Lead free product is acquired
Surface Mount Package
PE8203A应用：
Battery Protection
Load switch
PE8203A典型应用及引脚：
