PE8306是VDS=30V, ID=6A，RDS(ON)<28mΩ@VGS=10V，RDS(ON)<33mΩ@VGS=4.5V，RDS(ON)<50mΩ@VGS=2.5V的N沟道MOSFET。
PE8306的丝印是8306。PE8306提供SOT-23-3L封装。

The PE8306 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE8306概述：

PE8306是VDS=30V, ID=6A，RDS(ON)<28mΩ@VGS=10V，RDS(ON)<33mΩ@VGS=4.5V，RDS(ON)<50mΩ@VGS=2.5V的N沟道MOSFET。
PE8306的丝印是8306。PE8306提供SOT-23-3L封装。

The PE8306 uses advanced trench technology to provide excellent RDS(ON) and low gate charge. It can be used in a wide variety of applications.

PE8306特性：

VDS = 30V, ID = 6A

RDS(ON) < 28mΩ @ VGS=10V

RDS(ON) < 33mΩ @ VGS=4.5V

RDS(ON) < 50mΩ @ VGS=2.5V

High Power and current handing capability

Lead free product is acquired

Surface Mount Package

PE8306应用：

PWM applications

Load switch

Power management

PE8306典型应用及引脚：
