FM86C0规格书下载
FM86C0概述：
The FM86C0 is a low loss, high isolation SP12T switch for antenna TRX application.
The FM86C0 is compatible with MIPI control, which is a key requirement for many cellular transceivers. This part is packaged in a compact 2.5mm x 2.5mm, 20-pin, QFN package which allows for a small solution size with no need for external DC blocking capacitors (when no external DC is applied to the device ports).
FM86C0特性：
Excellent insertion loss - 0.80dB Insertion Loss at 2.7GHz
P0.1dB = 34dBm
Multi-Band operation 700MHz to 3000MHz
RFFE serial control interface
Compact 2.5mm x 2.5mm in QFN-20 package
No DC blocking capacitors required (unless external DC is applied to the RF ports)
FM86C0应用：
2G/3G/4G antenna TRX Application
Cellular modems and USB Devices
FM86C0功能框图和引脚配置：
FM86C0引脚示意图：
FM86C0引脚描述：
FM86C0引脚示意图：
FM86C0引脚描述：
