SLS80N03 Description/说明:
SLS80N03 is an N-channel enhanced mode power Mosfet with VDS=30V, ID=80A, RDS (ON) (TYP)=4m Ω @ VGS=10V, RDS (ON) (TYP)=7m Ω @ VGS=4.5V. Provide TO-252-2L packaging.
This Power SLS80N03 is produced using advanced TRENCH technology.
This advanced technology has been especially tailored to minimize conduction loss , provide superior switching
performance , and withstand high energy pulse i n the avalanche and commutation mode.
SLS80N03 General Features/一般特征：
VDS=30V, ID=50A
RDS(ON) (TYP)=4mΩ@VGS=10V
RDS(ON) (TYP)=7mΩ@VGS=4.5V
Very Low On- resistance RDS( ON)
Low Crss
Fast switching
10 0% avalanche tested
SLS80N03 Application/应用：
PWM applications
Load switch
Power management
