SLS50N03 Description/说明:
SLS50N03是VDS=30V, ID=50A，RDS(ON) (TYP)=7mΩ @VGS=10V，RDS(ON) (TYP)=10m Ω @VGS=4.5V的N-Mosfett。提供TO-252-2L封装。
This Power SLS50N03 is produced using advanced TRENCH technology. This advanced technology has been especially tailored to Minimize conduction loss , provide superior switching performance , and withstand high energy pulse in the avalanche and commutation mode.
SLS50N03 General Features/一般特征：
VDS=30V, ID=50A
RDS(ON) (TYP)=7mΩ@VGS=10V
RDS(ON) (TYP)=10m Ω @VGS=4.5V
Very Low On- resistance RDS( ON)
Low Crss
Fast switching
10 0% avalanche tested
SLS50N03 Application/应用：
PWM applications
Load switch
Power management
