CST4614C Description:
CST4614C is N-ch: BVDSS=40V, RDSON=26m Ω, ID=7.2A; P-ch: BVDSS=-40V, RDSON=62mΩ, N+P dual channel fast switching Mosfet with ID=-5.5A. Provide SOP8 packaging.
The CST4614C is the high performance complementary N-ch and P-ch MOSFETs with high cell density, which provide excellent RDSON and gate charge for most of the synchronous buck converter applications.
The CST4614C meet the RoHS and Green Product requirement 100% EAS guaranteed with full function reliability approved.
CST4614C Feature:
Green Device Available
Super Low Gate Charge
Excellent CdV/dt effect decline
Advanced high cell density Trench technology
CST4614C Product Summary：
|
BVDSS
|
RDSON
|
ID
|
|
40V |
26mΩ |
7.2A |
|
-40V |
62mΩ |
-5.5A |
CST4435 SOP8 Pin Configuration：
CST4435 SOP-8 Package Information：
