5G射频

FM1694

    The FM1694 is very low loss SPDT specifically designed for high performance antenna tuning applications. All RF path performance is enhanced with ultra-low on state resistance and off state capacitance.FM1694 allows the creation of advanced tuning topologies to maximize TRP & TIS performance in space constrained applications.

Ultra-Low On-resistance,1.0Ω
Off Ports, ‘open Type’
Two pin GPIO control Interface for standard SP4T operation
Very Small 1.1mm x 1.5mm, Laminate Package
Very low profile,0.44mm
2.5V to 4.8V Supply Range (VBATT Connect)
    LX1694概述:
        The FM1694 is very low loss SPDT specifically designed for high performance antenna tuning applications. All RF path performance is enhanced with ultra-low on state resistance and off state capacitance.FM1694 allows the creation of advanced tuning topologies to maximize TRP & TIS performance in space constrained applications.

    LX1694
    特性:
    Ultra-Low On-resistance,1.0Ω
    Off Ports, ‘open Type’
    Two pin GPIO control Interface for standard SP4T operation
    Very Small 1.1mm x 1.5mm, Laminate Package
    Very low profile,0.44mm
    2.5V to 4.8V Supply Range (VBATT Connect)

    LX1694
    应用:
    Antenna Tuning
    Band Switching
    Impedance Tuning

    LX1694功能
    框图:

    LX1694引脚示意图:



    LX1694引脚描述:
    LX1694应用示意图:
